Common Emitter/Collector Amplifier Board v3
Common Emitter/Collector Amplifier Board v3 - Image 2

Common Emitter/Collector Amplifier Board v3

7,95 € inc. VAT

Features Semi-Schematic board design With Transistor based Phase Splitter ‘Frees-style’ area for filters Create a fixed frequency signal Backside Ground Plane: For reduced noise emissions and optimal signal strength. Create any common emitter or common collector amplifier circuit based on transistors with this board. The standard layout makes it easy to try out various different […]

2 in stock (can be backordered)

SKU: amp_emi_col_v3
Category: ,

Description

Features

  • Semi-Schematic board design
  • With Transistor based Phase Splitter
  • ‘Frees-style’ area for filters
  • Create a fixed frequency signal
  • Backside Ground Plane: For reduced noise emissions and optimal signal strength.

Create any common emitter or common collector amplifier circuit based on transistors with this board. The standard layout makes it easy to try out various different applications of amplifier circuits.



PDF with Description

Under development.



Suggestions?

Do you have suggestions for improvements, or in need of a personalized PCB design, please write us.
